Miniature Copying

MiniCopy 35°

MiniCopy 35°

Best in class from ø12.5mm (ø .492")

MiniCopy 35° uses VCGT 0702 (VCGT 1.21.5) size inserts for diameters from ø12.5mm (ø .492").

Most popular

With a great range of lead angles and a comprehensive selection of inserts, this is our most popular copying solution.

Achieve the best!

With our VCGT 0702 (VCGT 1.21.5) inserts, you're going to be able to cut any material with ease.

Metric
Inch
5° SVOC | Cylindrical Boring Bars

5° SVOC

Cylindrical Boring Bars

KAPR
Insert size VC 0702
Screw T20.055
Torx driver T6F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E10H SVOCR-07 right 11 60 10 100 5.5
E12K SVOCR-07 right 13 72 12 125 6.5
E16M SVOCR-07 right 17 96 16 150 8.5
E10H SVOCL-07 left 11 60 10 100 5.5
E12K SVOCL-07 left 13 72 12 125 6.5
E16M SVOCL-07 left 17 96 16 150 8.5

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A10H SVOCR-07 right 11 40 10 100 5.5
A12K SVOCR-07 right 13 48 12 125 6.5
A16M SVOCR-07 right 17 64 16 150 8.5
A10H SVOCL-07 left 11 40 10 100 5.5
A12K SVOCL-07 left 13 48 12 125 6.5
A16M SVOCL-07 left 17 64 16 150 8.5

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S10H SVOCR-07 right 11 40 10 100 5.5
S12K SVOCR-07 right 13 48 12 125 6.5
S16M SVOCR-07 right 17 64 16 150 8.5
S10H SVOCL-07 left 11 40 10 100 5.5
S12K SVOCL-07 left 13 48 12 125 6.5
S16M SVOCL-07 left 17 64 16 150 8.5
113° SVXC | Stepped Boring Bars

113° SVXC

Stepped Boring Bars

KAPR 113°
Insert size VC 0702
Screw T20.055
Torx driver T6F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E10H SVXCR-07 right 12.5 60 10 100 7
E12K SVXCR-07 right 15.5 72 12 125 9
E16M SVXCR-07 right 17.5 55 16 150 11
E10H SVXCL-07 left 12.5 60 10 100 7
E12K SVXCL-07 left 15.5 72 12 125 9
E16M SVXCL-07 left 17.5 55 16 150 11

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A10H SVXCR-07 right 12.5 40 10 100 7
A12K SVXCR-07 right 15.5 48 12 125 9
A16M SVXCR-07 right 17.5 36 16 150 11
A10H SVXCL-07 left 12.5 40 10 100 7
A12K SVXCL-07 left 15.5 48 12 125 9
A16M SVXCL-07 left 17.5 36 16 150 11

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S10H SVXCR-07 right 12.5 40 10 100 7
S12K SVXCR-07 right 15.5 48 12 125 9
S16M SVXCR-07 right 17.5 36 16 150 11
S10H SVXCL-07 left 12.5 40 10 100 7
S12K SVXCL-07 left 15.5 48 12 125 9
S16M SVXCL-07 left 17.5 36 16 150 11
95° SVLC | Stepped Boring Bars

95° SVLC

Stepped Boring Bars

KAPR 95°
Insert size VC 0702
Screw T20.055
Torx driver T6F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E10H SVLCR-07 right 12.5 60 10 100 7
E12K SVLCR-07 right 15.5 72 12 125 9
E16M SVLCR-07 right 17.5 55 16 150 11
E10H SVLCL-07 left 12.5 60 10 100 7
E12K SVLCL-07 left 15.5 72 12 125 9
E16M SVLCL-07 left 17.5 55 16 150 11

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A10H SVLCR-07 right 12.5 40 10 100 7
A12K SVLCR-07 right 15.5 48 12 125 9
A16M SVLCR-07 right 17.5 36 16 150 11
A10H SVLCL-07 left 12.5 40 10 100 7
A12K SVLCL-07 left 15.5 48 12 125 9
A16M SVLCL-07 left 17.5 36 16 150 11

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S10H SVLCR-07 right 12.5 40 10 100 7
S12K SVLCR-07 right 15.5 48 12 125 9
S16M SVLCR-07 right 17.5 36 16 150 11
S10H SVLCL-07 left 12.5 40 10 100 7
S12K SVLCL-07 left 15.5 48 12 125 9
S16M SVLCL-07 left 17.5 36 16 150 11
72.5° SVVC | Stepped Boring Bars

72.5° SVVC

Stepped Boring Bars

KAPR 72.5°
Insert size VC 0702
Screw T20.055
Torx driver T6F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E10H SVVCR-07 right 13.5 60 10 100 8
E12K SVVCR-07 right 15.5 72 12 125 9
E16M SVVCR-07 right 17.5 55 16 150 11
E10H SVVCL-07 left 13.5 60 10 100 8
E12K SVVCL-07 left 15.5 72 12 125 9
E16M SVVCL-07 left 17.5 55 16 150 11

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A10H SVVCR-07 right 13.5 40 10 100 8
A12K SVVCR-07 right 15.5 48 12 125 9
A16M SVVCR-07 right 17.5 36 16 150 11
A10H SVVCL-07 left 13.5 40 10 100 8
A12K SVVCL-07 left 15.5 48 12 125 9
A16M SVVCL-07 left 17.5 36 16 150 11

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S10H SVVCR-07 right 13.5 40 10 100 8
S12K SVVCR-07 right 15.5 48 12 125 9
S16M SVVCR-07 right 17.5 36 16 150 11
S10H SVVCL-07 left 13.5 40 10 100 8
S12K SVVCL-07 left 15.5 48 12 125 9
S16M SVVCL-07 left 17.5 36 16 150 11
95° SVQC | Stepped Back Boring Bars

95° SVQC

Stepped Back Boring Bars

KAPR 95°
Insert size VC 0702
Screw T20.055
Torx driver T6F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E10H SVQCR-07 right 12.5 60 10 100 7
E12K SVQCR-07 right 15.5 72 12 125 9
E16M SVQCR-07 right 17.5 55 16 150 11
E10H SVQCL-07 left 12.5 60 10 100 7
E12K SVQCL-07 left 15.5 72 12 125 9
E16M SVQCL-07 left 17.5 55 16 150 11

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A10H SVQCR-07 right 12.5 40 10 100 7
A12K SVQCR-07 right 15.5 48 12 125 9
A16M SVQCR-07 right 17.5 36 16 150 11
A10H SVQCL-07 left 12.5 40 10 100 7
A12K SVQCL-07 left 15.5 48 12 125 9
A16M SVQCL-07 left 17.5 36 16 150 11

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S10H SVQCR-07 right 12.5 40 10 100 7
S12K SVQCR-07 right 15.5 48 12 125 9
S16M SVQCR-07 right 17.5 36 16 150 11
S10H SVQCL-07 left 12.5 40 10 100 7
S12K SVQCL-07 left 15.5 48 12 125 9
S16M SVQCL-07 left 17.5 36 16 150 11
Cutting Data Int'l
Cutting Data U.S.
Tool Holders Article Numbers
  • SVXCR 0808 D07
  • SVXCR 1010 E07
  • SVXCR 1212 F07
  • SVXCL 0808 D07
  • SVXCL 1010 E07
  • SVXCL 1212 F07
  • SVXCR "0505 D07
  • SVXCR "0606 E07
  • SVXCR "0808 F07
  • SVXCL "0505 D07
  • SVXCL "0606 E07
  • SVXCL "0808 F07
  • SVLCR 0808 D07
  • SVLCR 1010 E07
  • SVLCR 1212 F07
  • SVLCL 0808 D07
  • SVLCL 1010 E07
  • SVLCL 1212 F07
  • SVLCR "0505 D07
  • SVLCR "0606 E07
  • SVLCR "0808 F07
  • SVLCL "0505 D07
  • SVLCL "0606 E07
  • SVLCL "0808 F07
  • SVGCR 0808 K07
  • SVGCR 1010 M07
  • SVGCR 1212 M07
  • SVGCL 0808 K07
  • SVGCL 1010 M07
  • SVGCL 1212 M07
  • SVGCR "0505 K07
  • SVGCR "0606 M07
  • SVGCR "0808 M07
  • SVGCL "0505 K07
  • SVGCL "0606 M07
  • SVGCL "0808 M07
  • SVVCN 0808 K07
  • SVVCN 1010 M07
  • SVVCN 1212 M07
  • SVVCN "0505 K07
  • SVVCN "0606 M07
  • SVVCN "0808 M07
