MicroCopy G - Boring bars with GC04 inserts

from ⌀ 6 MM (.236")

MicroCopy G

Denitool Micro Boring Bars from ⌀ 6mm (.236") with GCGT 04T0.. size Inserts

Super small Copying Tool

Economic operation with high performance thanks to precision GCGT 04T0.. (GCGT 10.8...) inserts & hardened boring bar.

For small profiles and contours

Cut all profiles and contours with MicroCopy G 45° inserts. Great range of copying boring bars.

Universal

Trust our GCGT 04T0 (GCGT 10.8) insert size. Available in DX2 and DX70 universal coating.

Metric
Inch
5° SGOC | Stepped Boring Bars

5° SGOCR

Stepped Boring Bars

KAPR 5°
Insert size GC 04T0
Screw T16.035
Torx driver T5F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E06E SGOCR-04 right 6 18 6 70 2.5

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A06E SGOCR-04 right 6 10 6 70 2.5
113° SGXC | Stepped Boring Bars

113° SGXCR

Stepped Boring Bars

KAPR 113°
Insert size GC 04T0
Screw T16.035
Torx driver T5F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E06E SGXCR-04 right 7 18 6 70 3.9

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A06E SGXCR-04 right 7 10 6 70 3.9
95° SGLC | Stepped Boring Bars

95° SGLCR

Stepped Boring Bars

KAPR 95°
Insert size GC 04T0
Screw T16.035
Torx driver T5F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E06E SGLCR-04 right 7 18 6 70 3.9

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A06E SGLCR-04 right 7 10 6 70 3.9
67.5° SGVC | Stepped Boring Bars

67.5° SGVCR

Stepped Boring Bars

KAPR 67.5°
Insert size GC 04T0
Screw T16.035
Torx driver T5F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E06E SGVCR-04 right 7.5 36 6 70 4.3

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A06E SGVCR-04 right 7.5 24 6 70 4.3
95° SGQC | Stepped Back Boring Bars

95° SGQCR

Stepped Back Boring Bars

KAPR 95°
Insert size GC 04T0
Screw T16.035
Torx driver T5F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E06E SGQCR-04 right 7 18 6 70 3.9

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A06E SGVCR-04 right 7 10 6 70 3.9
