MicroCopy D - Boring Bars with DC04 inserts

FROM ⌀ 5.2 MM (.205")

MicroCopy D

Denitool MicroCopy D - Micro Turning Boring Bars

The smallest copying tool yet

For very small diameters from ⌀ 5.2 mm (.205"). With the small DCGT 04T0 (DCGT 10.8...) Inserts and complete carbide body with coolant through directly to the cutting tip.

High reliability

Trust in Denitool inserts in size DCGT 0401.. (DCGT 10.8). Available in DX2 and DX32 coating for all applications.

It can handle it

The ultra precise cut causes stable turning in all situations.

Metric
Inch
93° SDUCR | Stepped Boring Bars

93° SDUCR

Stepped Boring Bars

KAPR 93°
Insert size DC 04T0
Screw T16.035
Torx driver T5F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E05D SDUCR-04 right 5.6 18 5 60 3
107.5° SDQCR | Stepped Boring Bars

107.5° SDQCR

Stepped Boring Bars

KAPR 107.5°
Insert size DC 04T0
Screw T16.035
Torx driver T5F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E05D SDQCR-04 right 5.2 18 5 60 2.6
DC04 - Cutting Data Int'l
