Denitool ISO Standard Tools for Turning

Economic and versatile

Economical machining with precision indexable inserts from Denitool. Available in steel, with or without coolant hole and tungsten carbide with coolant hole, as well as shortened lower cost carbide boring bars. With Denitool boring bars you can achieve good chip flow properties. The cooling channels are directed directly under the chip to dissipate the resulting heat and break the chip. Thus, the service life can be significantly improved.

Standardised and innovative production methods.

ISO boring bars are characterised by the interchangeability of the components. The unique selling points for Denitool tools according to the ISO standard are the hardened pocket seats and production methods. In combination, this leads to favorable vibration behavior and tool wear.

ISO standard inserts

Due to the high range of workpiece materials, Denitool inserts are coordinated. With Denitool you have a complete program for your standardised workshop. For unusual applications, please contact our customer service.

Customers and prospects interested in IsoTools turning program enjoy direct contact with Denitool. Please contact us directly for your inquiry.

Contact Denitool
Metric
Inch
CC 0602 | 95° SCLC | Stepped Boring Bars

95° SCLC

Stepped Boring Bars

KAPR 95°
Insert size CC 0602
Screw T25.055
Torx driver T7F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E0608H SCLCR-06 right 8.5 28 8 100 4
E0810J SCLCR-06 right 11 36 10 110 6
E1012K SCLCR-06 right 13 44 12 125 7
E1216M SCLCR-06 right 16 55 16 150 9
E0608H SCLCL-06 left 8.5 28 8 100 4
E0810J SCLCL-06 left 11 36 10 110 6
E1012K SCLCL-06 left 13 44 12 125 7
E1216M SCLCL-06 left 16 55 16 150 9

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A0608H SCLCR-06 right 8.5 20 8 100 4
A0810J SCLCR-06 right 11 26 10 110 6
A1012K SCLCR-06 right 13 32 12 125 7
A1216M SCLCR-06 right 16 40 16 150 9
A0608H SCLCL-06 left 8.5 20 8 100 4
A0810J SCLCL-06 left 11 26 10 110 6
A1012K SCLCL-06 left 13 32 12 125 7
A1216M SCLCL-06 left 16 40 16 150 9

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S0608H SCLCR-06 right 8.5 20 8 100 4
S0810J SCLCR-06 right 11 26 10 110 6
S1012K SCLCR-06 right 13 32 12 125 7
S1216M SCLCR-06 right 16 40 16 150 9
S0608H SCLCL-06 left 8.5 20 8 100 4
S0810J SCLCL-06 left 11 26 10 110 6
S1012K SCLCL-06 left 13 32 12 125 7
S1216M SCLCL-06 left 16 40 16 150 9
CC 0602 | 95° SCLC | Cylindrical Boring Bars

95° SCLC

Cylindrical Boring Bars

KAPR 95°
Insert size CC 0602
Screw T25.055
Torx driver T7F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E08K SCLCR-06 right 11 48 8 125 6
E10H SCLCR-06 right 13 60 10 100 7
E10M SCLCR-06 right 13 60 10 150 7
E12K SCLCR-06 right 16 72 12 125 9
E12Q SCLCR-06 right 16 72 12 180 9
E16M SCLCR-06 right 20 96 16 150 11
E16R SCLCR-06 right 20 96 16 200 11
E08K SCLCL-06 left 11 48 8 125 6
E10H SCLCL-06 left 13 60 10 100 7
E10M SCLCL-06 left 13 60 10 150 7
E12K SCLCL-06 left 16 72 12 125 9
E12Q SCLCL-06 left 16 72 12 180 9
E16M SCLCL-06 left 20 96 16 150 11
E16R SCLCL-06 left 20 96 16 200 11

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A08F SCLCR-06 right 11 32 8 80 6
A10H SCLCR-06 right 13 40 10 100 7
A12K SCLCR-06 right 16 48 12 125 9
A16M SCLCR-06 right 20 64 16 150 11
A08F SCLCL-06 left 11 32 8 80 6
A10H SCLCL-06 left 13 40 10 100 7
A12K SCLCL-06 left 16 48 12 125 9
A16M SCLCL-06 left 20 64 16 150 11

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S08F SCLCR-06 right 11 32 8 80 6
S10H SCLCR-06 right 13 40 10 100 7
S12K SCLCR-06 right 16 48 12 125 9
S16M SCLCR-06 right 20 64 16 150 11
S08F SCLCL-06 left 11 32 8 80 6
S10H SCLCL-06 left 13 40 10 100 7
S12K SCLCL-06 left 16 48 12 125 9
S16M SCLCL-06 left 20 64 16 150 11
CC 09T3 | 95° SCLC | Cylindrical Boring Bars

95° SCLC

Cylindrical Boring Bars

KAPR 95°
Insert size CC 09T3
Screw T35.084
Torx driver T15H

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E16M SCLCR-09 right 21 96 16 150 11
E16R SCLCR-09 right 21 96 16 200 11
E20Q SCLCR-09 right 25 120 20 180 13
E20S SCLCR-09 right 25 120 20 250 13
E25R SCLCR-09 right 31.5 150 25 200 17
E25T SCLCR-09 right 31.5 150 25 300 17
E16M SCLCL-09 left 21 96 16 150 11
E16R SCLCL-09 left 21 96 16 200 11
E20Q SCLCL-09 left 25 120 20 180 13
E20S SCLCL-09 left 25 120 20 250 13
E25R SCLCL-09 left 31.5 150 25 200 17
E25T SCLCL-09 left 31.5 150 25 300 17

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A16M SCLCR-09 right 21 64 16 150 11
A20Q SCLCR-09 right 25 80 20 180 13
A25R SCLCR-09 right 31.5 100 25 200 17
A16M SCLCL-09 left 21 64 16 150 11
A20Q SCLCL-09 left 25 80 20 180 13
A25R SCLCL-09 left 31.5 100 25 200 17

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S16M SCLCR-09 right 21 64 16 150 11
S20Q SCLCR-09 right 25 80 20 180 13
S25R SCLCR-09 right 31.5 100 25 200 17
S16M SCLCL-09 left 21 64 16 150 11
S20Q SCLCL-09 left 25 80 20 180 13
S25R SCLCL-09 left 31.5 100 25 200 17
DC 0702 | 107.5° SDQC | Stepped Boring Bars

107.5° SDQC

Stepped Boring Bars

KAPR 107.5°
Insert size DC 0702
Screw T25.055
Torx driver T7F

The image shows the right-hand tool.

search insert
Tool Drawing

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A0810H SDQCR-07 right 12.8 40 10 100 7
A1012K SDQCR-07 right 15.8 48 12 125 9
A1216M SDQCR-07 right 19.2 64 16 150 11
A0810H SDQCL-07 left 12.8 40 10 100 7
A1012K SDQCL-07 left 15.8 48 12 125 9
A1216M SDQCL-07 left 19.2 64 16 150 11

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S0810H SDQCR-07 right 12.8 40 10 100 7
S1012K SDQCR-07 right 15.8 48 12 125 9
S1216M SDQCR-07 right 19.2 64 16 150 11
S0810H SDQCL-07 left 12.8 40 10 100 7
S1012K SDQCL-07 left 15.8 48 12 125 9
S1216M SDQCL-07 left 19.2 64 16 150 11
DC 0702 | 107.5° SDQC | Cylindrical Boring Bars

107.5° SDQC

Cylindrical Boring Bars

KAPR 107.5°
Insert size DC 0702
Screw T25.055
Torx driver T7F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E10H SDQCR-07 right 14 60 10 100 7
E10M SDQCR-07 right 14 60 10 150 7
E12K SDQCR-07 right 17 72 12 125 9
E12Q SDQCR-07 right 17 72 12 180 9
E16M SDQCR-07 right 21 96 16 150 11
E16R SDQCR-07 right 21 96 16 200 11
E20Q SDQCR-07 right 25 120 20 180 13
E20S SDQCR-07 right 25 120 20 250 13
E10H SDQCL-07 left 14 60 10 100 7
E10M SDQCL-07 left 14 60 10 150 7
E12K SDQCL-07 left 17 72 12 125 9
E12Q SDQCL-07 left 17 72 12 180 9
E16M SDQCL-07 left 21 96 16 150 11
E16R SDQCL-07 left 21 96 16 200 11
E20Q SDQCL-07 left 25 120 20 180 13
E20S SDQCL-07 left 25 120 20 250 13

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A10H SDQCR-07 right 14 40 10 100 7
A12K SDQCR-07 right 17 48 12 125 9
A16M SDQCR-07 right 21 64 16 150 11
A20Q SDQCR-07 right 25 80 20 180 13
A10H SDQCL-07 left 14 40 10 100 7
A12K SDQCL-07 left 17 48 12 125 9
A16M SDQCL-07 left 21 64 16 150 11
A20Q SDQCL-07 left 25 80 20 180 13

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S10H SDQCR-07 right 14 40 10 100 7
S12K SDQCR-07 right 17 48 12 125 9
S16M SDQCR-07 right 21 64 16 150 11
S20Q SDQCR-07 right 25 80 20 180 13
S10H SDQCL-07 left 14 40 10 100 7
S12K SDQCL-07 left 17 48 12 125 9
S16M SDQCL-07 left 21 64 16 150 11
S20Q SDQCL-07 left 25 80 20 180 13
DC 11T3 | 107.5° SDQC | Cylindrical Boring Bars

107.5° SDQC

Cylindrical Boring Bars

KAPR 107.5°
Insert size DC 11T3
Screw T35.084
Torx driver T15H

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E20Q SDQCR-11 right 25 120 20 180 13
E20S SDQCR-11 right 25 120 20 250 13
E25R SDQCR-11 right 31.5 150 25 200 17
E25T SDQCR-11 right 31.5 150 25 300 17
E20Q SDQCL-11 left 25 120 20 180 13
E20S SDQCL-11 left 25 120 20 250 13
E25R SDQCL-11 left 31.5 150 25 200 17
E25T SDQCL-11 left 31.5 150 25 300 17

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A20Q SDQCR-11 right 25 80 20 180 13
A25R SDQCR-11 right 31.5 100 25 200 17
A20Q SDQCL-11 left 25 80 20 180 13
A25R SDQCL-11 left 31.5 100 25 200 17

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S20Q SDQCR-11 right 25 80 20 180 13
S25R SDQCR-11 right 31.5 100 25 200 17
S20Q SDQCL-11 left 25 80 20 180 13
S25R SDQCL-11 left 31.5 100 25 200 17
DC 0702 | 93° SDUC | Stepped Boring Bars

93° SDUC

Stepped Boring Bars

KAPR 93°
Insert size DC 0702
Screw T25.055
Torx driver T7F

The image shows the right-hand tool.

search insert
Tool Drawing

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A0810H SDUCR-07 right 12.8 40 10 100 7
A1012K SDUCR-07 right 15.8 48 12 125 9
A1216M SDUCR-07 right 19.2 64 16 150 11
A0810H SDUCL-07 left 12.8 40 10 100 7
A1012K SDUCL-07 left 15.8 48 12 125 9
A1216M SDUCL-07 left 19.2 64 16 150 11

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S0810H SDUCR-07 right 12.8 40 10 100 7
S1012K SDUCR-07 right 15.8 48 12 125 9
S1216M SDUCR-07 right 19.2 64 16 150 11
S0810H SDUCL-07 left 12.8 40 10 100 7
S1012K SDUCL-07 left 15.8 48 12 125 9
S1216M SDUCL-07 left 19.2 64 16 150 11
DC 0702 | 93° SDUC | Cylindrical Boring Bars

93° SDUC

Cylindrical Boring Bars

KAPR 93°
Insert size DC 0702
Screw T25.055
Torx driver T7F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E10H SDUCR-07 right 14 60 10 100 7
E10M SDUCR-07 right 14 60 10 150 7
E12K SDUCR-07 right 17 72 12 125 9
E12Q SDUCR-07 right 17 72 12 180 9
E16M SDUCR-07 right 21 96 16 150 11
E16R SDUCR-07 right 21 96 16 200 11
E20S SDUCR-07 right 25 120 20 180 13
E20S SDUCR-07 right 25 120 20 250 13
E10H SDUCL-07 left 14 60 10 100 7
E10M SDUCL-07 left 14 60 10 150 7
E12K SDUCL-07 left 17 72 12 125 9
E12Q SDUCL-07 left 17 72 12 180 9
E16M SDUCL-07 left 21 96 16 150 11
E16R SDUCL-07 left 21 96 16 200 11
E20Q SDUCL-07 left 25 120 20 180 13
E20S SDUCL-07 left 25 120 20 250 13

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A10H SDUCR-07 right 14 40 10 100 7
A12K SDUCR-07 right 17 48 12 125 9
A16M SDUCR-07 right 21 64 16 150 11
A20Q SDUCR-07 right 25 80 20 180 13
A10H SDUCL-07 left 14 40 10 100 7
A12K SDUCL-07 left 17 48 12 125 9
A16M SDUCL-07 left 21 64 16 150 11
A20Q SDUCL-07 left 25 80 20 180 13

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S10H SDUCR-07 right 14 40 10 100 7
S12K SDUCR-07 right 17 48 12 125 9
S16M SDUCR-07 right 21 64 16 150 11
S20Q SDUCR-07 right 25 80 20 180 13
S10H SDUCL-07 left 14 40 10 100 7
S12K SDUCL-07 left 17 48 12 125 9
S16M SDUCL-07 left 21 64 16 150 11
S20Q SDUCL-07 left 25 80 20 180 13
DC 11T3 | 93° SDUC | Cylindrical Boring Bars

93° SDUC

Cylindrical Boring Bars

KAPR 93°
Insert size DC 11T3
Screw T35.084
Torx driver T15H

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E20Q SDUCR-11 right 25 120 20 180 13
E20S SDUCR-11 right 25 120 20 250 13
E25R SDUCR-11 right 31.5 150 25 200 17
E25T SDUCR-11 right 31.5 150 25 300 17
E20Q SDUCL-11 left 25 120 20 180 13
E20S SDUCL-11 left 25 120 20 250 13
E25R SDUCL-11 left 31.5 150 25 200 17
E25T SDUCL-11 left 31.5 150 25 300 17

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A20Q SDUCR-11 right 25 80 20 180 13
A25R SDUCR-11 right 31.5 100 25 200 17
A20Q SDUCL-11 left 25 80 20 180 13
A25R SDUCL-11 left 31.5 100 25 200 17

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S20Q SDUCR-11 right 25 80 20 180 13
S25R SDUCR-11 right 31.5 100 25 200 17
S20Q SDUCL-11 left 25 80 20 180 13
S25R SDUCL-11 left 31.5 100 25 200 17
DC 0702 | 93° SDXC | Cylindrical Back Boring Bars

93° SDXC

Cylindrical Back Boring Bars

KAPR 93°
Insert size DC 0702
Screw T25.055
Torx driver T7F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E12K SDXCR-07 right 17 72 12 125 10.5
E12Q SDXCR-07 right 17 72 12 180 10.5
E16M SDXCR-07 right 21 96 16 150 12.5
E16R SDXCR-07 right 21 96 16 200 12.5
E12K SDXCL-07 left 17 72 12 125 10.5
E12Q SDXCL-07 left 17 72 12 180 10.5
E16M SDXCL-07 left 21 96 16 150 12.5
E16R SDXCL-07 left 21 96 16 200 12.5

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A12K SDXCR-07 right 17 48 12 125 10.5
A16M SDXCR-07 right 21 64 16 150 12.5
A12K SDXCL-07 left 17 48 12 125 10.5
A16M SDXCL-07 left 21 64 16 150 12.5

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S12K SDXCR-07 right 17 48 12 125 10.5
S16M SDXCR-07 right 21 64 16 150 12.5
S12K SDXCL-07 left 17 48 12 125 10.5
S16M SDXCL-07 left 21 64 16 150 12.5
DC 11T3 | 93° SDXC | Cylindrical Back Boring Bars

93° SDXC

Cylindrical Back Boring Bars

KAPR 93°
Insert size DC 11T3
Screw T35.084
Torx driver T15H

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E20Q SDXCR-11 right 31 120 20 180 20
E20S SDXCR-11 right 31 120 20 250 20
E25R SDXCR-11 right 36 150 25 200 22.5
E25T SDXCR-11 right 36 150 25 300 22.5
E20Q SDXCL-11 left 31 120 20 180 20
E20S SDXCL-11 left 31 120 20 250 20
E25R SDXCL-11 left 36 150 25 200 22.5
E25T SDXCL-11 left 36 150 25 300 22.5

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A20Q SDXCR-11 right 31 80 20 180 20
A25R SDXCR-11 right 36 100 25 200 22.5
A20Q SDXCL-11 left 31 80 20 180 20
A25R SDXCL-11 left 36 100 25 200 22.5

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S20Q SDXCR-11 right 31 80 20 180 20
S25R SDXCR-11 right 36 100 25 200 22.5
S20Q SDXCL-11 left 31 80 20 180 20
S25R SDXCL-11 left 36 100 25 200 22.5
Cutting Data Int'l - (CC06, CC09, DC07, DC11, TC11, TC16, VC11)
Cutting Data U.S. - (CC06, CC09, DC07, DC11, TC11, TC16, VC11)
Tool Holders Article Numbers
  • SDNCN 0808 D07
  • SDNCN 1010 E07
  • SDNCN 1212 F07
  • SDNCN 1616 H11
  • SDNCN 2020 K11
  • SDNCN 2525 M11
  • SDNCN "0505 D07
  • SDNCN "0606 E07
  • SDNCN "0808 F07
  • SDNCN "1010 H11
  • SDNCN "1212 K11
  • SDNCN "1616 M11
  • SDJCR 0808 D07
  • SDJCR 1010 E07
  • SDJCR 1212 F07
  • SDJCR 1616 H11
  • SDJCR 2020 K11
  • SDJCR 2525 M11
  • SDJCR "0505 D07
  • SDJCR "0606 E07
  • SDJCR "0808 F07
  • SDJCR "1010 H11
  • SDJCR "1212 K11
  • SDJCR "1616 M11
  • SDJCL 0808 D07
  • SDJCL 1010 E07
  • SDJCL 1212 F07
  • SDJCL 1616 H11
  • SDJCL 2020 K11
  • SDJCL 2525 M11
  • SDJCL "0505 D07
  • SDJCL "0606 E07
  • SDJCL "0808 F07
  • SDJCL "1010 H11
  • SDJCL "1212 K11
  • SDJCL "1616 M11
  • SDHCR 1010 E07
  • SDHCR 1212 F07
  • SDHCR 1616 H11
  • SDHCR 2020 K11
  • SDHCR 2525 M11
  • SDHCR "0606 E07
  • SDHCR "0808 F07
  • SDHCR "1010 H11
  • SDHCR "1212 K11
  • SDHCR "1616 M11
  • SDHCL 1010 E07
  • SDHCL 1212 F07
  • SDHCL 1616 H11
  • SDHCL 2020 K11
  • SDHCL 2525 M11
  • SDHCL "0606 E07
  • SDHCL "0808 F07
  • SDHCL "1010 H11
  • SDHCL "1212 K11
  • SDHCL "1616 M11
  • SCLCR 0808 D06
  • SCLCR 1010 E06
  • SCLCR 1212 F09
  • SCLCR 1616 H09
  • SCLCR 2020 K09
  • SCLCR "0505 D06
  • SCLCR "0606 E06
  • SCLCR "0808 F09
  • SCLCR "1010 H09
  • SCLCR "1212 K09
  • SCLCL 0808 D06
  • SCLCL 1010 E06
  • SCLCL 1212 F09
  • SCLCL 1616 H09
  • SCLCL 2020 K09
  • SCLCL "0505 D06
  • SCLCL "0606 E06
  • SCLCL "0808 F09
  • SCLCL "1010 H09
  • SCLCL "1212 K09
