Copy 35° - Copying, Profiling with VC13 inserts

Copy 35°

good quality is economical

Economic operation with well known Denitool performance thanks to highly precise VCGT 1303.. (VCGT 2.52...) inserts & holders.

machine well

Extremely precise carbide inserts with a great range of geometries and coatings available.

reliable

High lifetime and longer replacement cycles are Copy 35°characteristics.

Denitool Turning Tools
Metric
Inch
5° SVOC | Cylindrical Boring Bars

5° SVOC

Cylindrical Boring Bars

KAPR 5°
Insert size VC 1303
Screw T30.090
Torx driver T8F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E16M SVOCR-13 right 20 96 16 150 11
E16R SVOCR-13 right 20 96 16 200 11
E20Q SVOCR-13 right 23 120 20 180 12.5
E20S SVOCR-13 right 23 120 20 250 12.5
E25R SVOCR-13 right 30 150 25 200 16.5
E25T SVOCR-13 right 30 150 25 300 16.5
E16M SVOCL-13 left 20 96 16 150 11
E16R SVOCL-13 left 20 96 16 200 11
E20Q SVOCL-13 left 23 120 20 180 12.5
E20S SVOCL-13 left 23 120 20 250 12.5
E25R SVOCL-13 left 30 150 25 200 16.5
E25T SVOCL-13 left 30 150 25 300 16.5

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A16Q SVOCR-13 right 20 64 16 180 11
A20R SVOCR-13 right 23 80 20 200 12.5
A25S SVOCR-13 right 30 100 25 250 16.5
A16Q SVOCL-13 left 20 64 16 180 11
A20R SVOCL-13 left 23 80 20 200 12.5
A25S SVOCL-13 left 30 100 25 250 16.5

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S16Q SVOCR-13 right 20 64 16 180 11
S20R SVOCR-13 right 23 80 20 200 12.5
S25S SVOCR-13 right 30 100 25 250 16.5
S16Q SVOCL-13 left 20 64 16 180 11
S20R SVOCL-13 left 23 80 20 200 12.5
S25S SVOCL-13 left 30 100 25 250 16.5
113° SVXC | Stepped Boring Bars

113° SVXC

Stepped Boring Bars

KAPR 113°
Insert size VC 1303
Screw T30.090
Torx driver T8F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E16M SVXCR-13 right 21 96 16 150 11
E16R SVXCR-13 right 21 96 16 200 11
E20Q SVXCR-13 right 25 120 20 180 13
E20S SVXCR-13 right 25 120 20 250 13
E25R SVXCR-13 right 32 150 25 200 17
E25T SVXCR-13 right 32 150 25 300 17
E16M SVXCL-13 left 21 96 16 150 11
E16R SVXCL-13 left 21 96 16 200 11
E20Q SVXCL-13 left 25 120 20 180 13
E20S SVXCL-13 left 25 120 20 250 13
E25R SVXCL-13 left 32 150 25 200 17
E25T SVXCL-13 left 32 150 25 300 17

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A16Q SVXCR-13 right 21 64 16 180 11
A20R SVXCR-13 right 25 80 20 200 13
A25S SVXCR-13 right 32 100 25 250 17
A32T SVXCR-13 right 40 128 32 300 22
A16Q SVXCL-13 left 21 64 16 180 11
A20R SVXCL-13 left 25 80 20 200 13
A25S SVXCL-13 left 32 100 25 250 17
A32T SVXCL-13 left 40 128 32 300 22

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S16Q SVXCR-13 right 21 64 16 180 11
S20R SVXCR-13 right 25 80 20 200 13
S25S SVXCR-13 right 32 100 25 250 17
S32T SVXCR-13 right 40 128 32 300 22
S16Q SVXCL-13 left 21 64 16 180 11
S20R SVXCL-13 left 25 80 20 200 13
S25S SVXCL-13 left 32 100 25 250 17
S32T SVXCL-13 left 40 128 32 300 22
95° SVLC | Stepped Boring Bars

95° SVLC

Stepped Boring Bars

KAPR 95°
Insert size VC 1303
Screw T30.090
Torx driver T8F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E20Q SVLCR-13 right 25 120 20 180 13
E20S SVLCR-13 right 25 120 20 250 13
E25R SVLCR-13 right 32 150 25 200 17
E25T SVLCR-13 right 32 150 25 300 17
E20Q SVLCL-13 left 25 120 20 180 13
E20S SVLCL-13 left 25 120 20 250 13
E25R SVLCL-13 left 32 150 25 200 17
E25T SVLCL-13 left 32 150 25 300 17

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A20R SVLCR-13 right 25 80 20 200 13
A25S SVLCR-13 right 32 100 25 250 17
A32T SVLCR-13 right 40 128 32 300 22
A20R SVLCL-13 left 25 80 20 200 13
A25S SVLCL-13 left 32 100 25 250 17
A32T SVLCL-13 left 40 128 32 300 22

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S20R SVLCR-13 right 25 80 20 200 13
S25S SVLCR-13 right 32 100 25 250 17
S32T SVLCR-13 right 40 128 32 300 22
S20R SVLCL-13 left 25 80 20 200 13
S25S SVLCL-13 left 32 100 25 250 17
S32T SVLCL-13 left 40 128 32 300 22
72.5° SVVC | Stepped Boring Bars

72.5° SVVC

Stepped Boring Bars

KAPR 72.5°
Insert size VC 1303
Screw T30.090
Torx driver T8F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E20Q SVVCR-13 right 27 120 20 180 15
E20S SVVCR-13 right 27 120 20 250 15
E25R SVVCR-13 right 32 150 25 200 17
E25T SVVCR-13 right 32 150 25 300 17
E20Q SVVCL-13 left 27 120 20 180 15
E20S SVVCL-13 left 27 120 20 250 15
E25R SVVCL-13 left 32 150 25 200 17
E25T SVVCL-13 left 32 150 25 300 17

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A20R SVVCR-13 right 27 80 20 200 15
A25S SVVCR-13 right 32 100 25 250 17
A32T SVVCR-13 right 40 128 32 300 22
A20R SVVCL-13 left 27 80 20 200 15
A25S SVVCL-13 left 32 100 25 250 17
A32T SVVCL-13 left 40 128 32 300 22

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S20R SVVCR-13 right 27 80 20 200 15
S25S SVVCR-13 right 32 100 25 250 17
S32T SVVCR-13 right 40 128 32 300 22
S20R SVVCL-13 left 27 80 20 200 15
S25S SVVCL-13 left 32 100 25 250 17
S32T SVVCL-13 left 40 128 32 300 22
95° SVQC | Stepped Back Boring Bars

95° SVQC

Stepped Back Boring Bars

KAPR 95°
Insert size VC 1303
Screw T30.090
Torx driver T8F

The image shows the right-hand tool.

search insert
Tool Drawing

Carbide Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
E20Q SVQCR-13 right 27 120 20 180 15
E20S SVQCR-13 right 27 120 20 250 15
E25R SVQCR-13 right 35 150 25 200 20
E25T SVQCR-13 right 35 150 25 300 20
E20Q SVQCL-13 left 27 120 20 180 15
E20S SVQCL-13 left 27 120 20 250 15
E25R SVQCL-13 left 35 150 25 200 20
E25T SVQCL-13 left 35 150 25 300 20

Steel Shank | w/ coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
A20R SVQCR-13 right 27 80 20 200 15
A25S SVQCR-13 right 35 100 25 250 20
A32T SVQCR-13 right 43 128 32 300 25
A20R SVQCL-13 left 27 80 20 200 15
A25S SVQCL-13 left 35 100 25 250 20
A32T SVQCL-13 left 43 128 32 300 25

Steel Shank | w/o coolant channel

Order-no. Hand DMIN CLMBD DCON LF WF
S20R SVQCR-13 right 27 80 20 200 15
S25S SVQCR-13 right 35 100 25 250 20
S32T SVQCR-13 right 43 128 32 300 25
S20R SVQCL-13 left 27 80 20 200 15
S25S SVQCL-13 left 35 100 25 250 20
S32T SVQCL-13 left 43 128 32 300 25
